Brand:OMATEI
Selection Guidance
1, Chuck brand and model name
2, Workpiece size and the gripping height
Advantage
1, For standard soft jaws, the material is high quality 45# steel, stronger and hardenable.
2, Fine serration pitch can tight fit with chuck master jaws, lower abrasion.
3, Applicable onto the related chuck models of SMW/Kitagawa/Soul/Howa/Samchully/Auto-strong/Tonfou/Chandox/Autogrip/NTH and so on well-known brand.
4, Customized and non-standard jaws and be designed and OEM.
|
SPEC
MODEL
|
H-1
|
H-2
|
H-3
|
H-4
|
H-5
|
H-6
|
H-7
|
H-8
|
H-9
|
H-10
|
Serration
Pitch
|
Gross
Weight(kg)
|
Ref
|
|
HJ-05
|
53
|
23
|
28
|
10
|
4
|
30.5
|
14
|
22.5
|
10
|
M8
|
1.5×60°
|
0.4
|
Fig2
|
|
HJ-06
|
67
|
31
|
36
|
12
|
5
|
39
|
20
|
28
|
12
|
M10
|
1.5×60°
|
0.95
|
Fig2
|
HJ-06-3
|
67
|
31
|
49
|
12
|
5
|
18
|
20
|
19
|
12
|
M10
|
1.5×60°
|
1
|
Fig1
|
|
HJ-08
|
86
|
35
|
51
|
14
|
5
|
31
|
25
|
18
|
12
|
M12
|
1.5×60°
|
1.95
|
Fig1
|
|
HJ-10
|
100
|
40
|
54
|
16
|
5
|
43
|
30
|
17
|
14
|
M12
|
1.5×60°
|
2.85
|
Fig1
|
|
HJ-12
|
103
|
50
|
52
|
21(18)
|
5
|
69.5
|
30
|
43.5
|
20
|
M16(M14)
|
1.5×60°
|
3.9
|
Fig2
|
HJ-12-3
|
103
|
50
|
66
|
21(18)
|
5
|
36
|
30
|
32
|
15
|
M16(M14)
|
1.5×60°
|
4.2
|
Fig1
|
|
HJ-1518
|
149
|
62
|
86
|
22(25.5)
|
8(5)
|
55
|
43
|
38
|
20
|
M20
|
1.5×60°
|
9.45
|
Fig1
|
|
HJ-15-1
|
149
|
62
|
86
|
26
|
8
|
55
|
43
|
38
|
20
|
M20
|
3.0×60°
|
9.45
|
Fig1
|
|
HJ-2421
|
159.5
|
80
|
90
|
25
|
9
|
104.5
|
50
|
55
|
40
|
M20
|
3.0×60°
|
14.3
|
Fig2
|
|
HJ-32
|
159.5
|
80
|
90
|
25
|
9
|
104.5
|
50
|
55
|
40
|
M20
|
3.0×60°
|
14.3
|
Fig2
|
|
HJ-40(50)
|
223
|
85
|
117
|
30
|
7
|
76.2
|
38.1
|
140
|
83
|
M24
|
|
|
Fig3
|
|
HJ-63(79)
|
223
|
110
|
117
|
30
|
7
|
76.2
|
38.1
|
140
|
83
|
M24
|
|
|
Fig3
|
Other option of serration pitch: 3.0*60°
Subject to technical changes
